Aluminium Honeycomb Panels /SGS certificate Honeycomb Cladding Panel
Product Information:
WHOLETOPS brand sandwich panel is the most widely used honeycomb panel, utilized in building facades, ceilings, decorations, furniture and more.
Fire-proofing: Grade A
Sound insulation: weight-counted sound insulation quantity 25dB
Thermal Insulation:Thermal conductivity 0.527W/m·K
Strong weather resistance:the material is self-cleaning. Using rolling coating technology with 70% flurocarbon.
Minimum radius of arc slab is 300mm, its one-time process forming no need second time process.ensure no damage to the panel strength.
Product Overview:
Material:Aluminum
Aluminum Alloy:1100/3003/5005
Thickness:12mm-24mm
Surface Treatment:PVDF Coated/Powder Coated
Size:Customized
Coating Brand:PPG/Akzo Nobel
Color:Customized
Warranty:10-20years
Packing:Wooden Box
Class Fire Prevention:A2
MOQ:Negotiable
Specification:
1. Total Thickness: 8mm, 10mm , 12mm, 15mm, 18mm, 20mm, 22mm, 24mm,25mm and so on.
2. Top Panel: aluminum alloy sheet coated with fluro-carbon resin((PVDF) coating with 0.8 – 1.0 mm thickness.
3. Core: aluminum honeycomb core
4. Bottom Panel: aluminum sheet with PVDF coated / Power coated with 0.8—1.0mm thickness
5. Surface finish: PVDF coated / Power coated/ Pre Rolled
6. Aluminum Alloy: 1100/3003/5005
7. size: width ≤ 1500mm, length ≤ 5800mm
Product advantages:
1. light and straightness
2. excellent rigidness
3. high intensity
4. wind pressure resistance
5. fireproof, sound and thermal insulation, shock absorption
6. even coating and various colors
7. easy to maintain and environmental protection
Scopes of Application:
1. Building exterior walls decoration (especially for high-rise building)Curtain wall decoration, advertising aboard, signboards,ceiling etc.
2. Interior decoration, wall partitions, door, ceiling
3. Advertising board , signboards,insulation cars,
4. prototype of cabinet and so on
Our Company
Our workshop
Our Recently Project with Aluminum Honeycomb Panel :
Shenzhen Nantai Inno Park
Packing & Lading
